Detectable Woven Polyester Pulling Tape – 22 Gauge Conductor
Highlights
- 100% woven polyester pull tape
- High tensile strength, low stretch
- Integrated 22-gauge copper conductor for detection
- Sequential footage markings for precise measurements
- Pre-lubricated to reduce friction, duct wear
- Available in custom lengths and reel sizes
Description
Our detachable woven polyester pulling tape is engineered for professionals who need a reliable, detectable solution for cable installations. Made from 100% high-strength, low-stretch polyester, this tape offers both durability and precision, ensuring smooth cable pulls through conduits with minimal friction.
The integrated 22-gauge copper conductor allows for easy detection and location of cables within conduits. Sequential footage markings make it simple to measure and track cable installations accurately. Lightweight and flexible, it can be easily blown through conduits and is conveniently packaged on heavy-duty black plastic reels for effortless handling and deployment on-site.
Available in tensile strengths of up to 2,500 lbs. and reel lengths of up to 100,000 feet*, this tape is ideal for large-scale projects requiring long, continuous pulls.
*Other tensile strengths & custom lengths available upon request.
Click button to download the cut sheet automatically
| Part Number | Tensile Strength lbs. | Approximate Width in. | Length ft. | Maximum Reel Length ft. |
|---|---|---|---|---|
| WPD12503000 | 1,250 | 1/2 | 3,000 | 100,000 |
| WPD12505000 | 1,250 | 1/2 | 5,000 | 100,000 |
| WPD18003000 | 1,800 | 5/8 | 3,000 | 60,000 |
| WPD18005000 | 1,800 | 5/8 | 5,000 | 60,000 |
| WPD25003000 | 2,500 | 3/4 | 3,000 | 45,000 |
| WPD25005000 | 2,500 | 3/4 | 5,000 | 45,000 |
- Detectable Conductor: The built-in 22-gauge copper wire allows for easy tracing and detection of cables within conduits, increasing safety and accuracy.
- High Strength: Made from 100% woven polyester, the tape offers a tensile strength of up to 2,500 lbs., perfect for heavy-duty cable pulling.
- Low Stretch: Minimal elongation ensures accurate cable placement and reduced risk of snapping during pulls.
- Accurate Footage Markings: Sequential markings allow precise measurement and easy progress tracking during installation, reducing errors.
- Pre-lubricated: The tape comes pre-lubricated to minimize friction, making it easier to pull cables through conduits and reducing wear on the tape and conduit walls.
- Durability: Resistant to mildew, UV rays, and abrasion, ensuring longevity even in harsh outdoor or underground environments.
To prolong the life of your woven polyester cable pulling tape, store it in a cool, dry place to avoid exposure to moisture and UV light. Regularly inspect the tape for signs of wear, especially after pulling through conduits or ducts. If the tape becomes frayed or damaged, replace it immediately to avoid any performance issues during future cable installations. Ensure proper lubrication of the tape during use to reduce friction and extend its durability.
